NET-UBQ-PWS-USP-RPS
NET-UBQ-PWS-USP-RPS
NET-UBQ-PWS-USP-RPS
Ubiquiti UniFi Redundant Power System
Local Support in Australia and New Zealand
Quick Delivery Wide stock availability to respond to most requirements.
Our specialist support is available!
The Ubiquiti USP-RPS (UniFi SmartPower Redundant Power System) is a high-performance, rack-mountable backup power solution designed to ensure seamless operation of up to six UniFi devices in the event of a power supply failure.
With a 950W power budget and six dedicated USP DC output ports, it is ideal for safeguarding mission-critical devices like UniFi PoE switches.
The system features an automatic failover mechanism, allowing uninterrupted operation during power supply interruptions.
Additionally, it comes equipped with a 1.3" colour touchscreen for real-time monitoring and is managed via the UniFi Network Controller.
This robust solution ensures continuous power to keep your network running smoothly even in the most demanding environments.
Mechanical |       | |
Dimensions | 442.4 x 325.6 x 43.7 mm | |
Weight | Without mounting brackets: 5.5 kg
With mounting brackets: 5.6 kg | |
Enclosure material | SGCC steel | |
Hardware |       | |
Networking interface | (1) GbE RJ45 port | |
Management interface | Ethernet In-Band | |
Power output | (6) RPS DC ports | |
Power method | (1) Universal input, 100—240V AC | |
Max. power consumption | 995W | |
Power supply | Internal 350W AC/DC
Internal 645W AC/DC |
|
Supported voltage range | 100—240V AC | |
Total output power | ||
52V DC | 11.54A (600W) | |
11.5V DC | 30.44A (350W) | |
Max. output power per RPS port | ||
52V DC | 11.54A (600W) | |
11.5V DC | 30.44A (350W) | |
Display | 1.3" touchscreen | |
ESD/EMP protection | Air: ± 16kV, contact: ± 12kV | |
Ambient operating temperature | -5 to 45° C | |
Ambient operating humidity | 10 to 90% noncondensing | |
Certifications | CE, FCC, IC | |
LEDs |       | |
System | Status | |
Ethernet | Link/activity | |
USP RPS | Activity |
Section Name | Description |
---|---|
Mpn | USP-RPS |
Brand | Ubiquiti |
